	SI-111-SS	SI-121-SS	SI-131-SS	SI-1H1-SS	SIF-111-SS	SIF-121-SS	SIF-1H1-SS
Analog Model Output (Difference between Target and Detector)	60 µV per C	40µV/C	20 µV per C	40µV/C	15µV/C	10 µV per C	10 µV per C
Thermistor Input Voltage Requirement	2500 mV励磁（典型，可使用其他电压）	2500 mV励磁（典型，可使用其他电压）	2500 mV励磁（典型，可使用其他电压）	2500 mV励磁（典型，可使用其他电压）	2500 mV励磁（典型，可使用其他电压）	2500 mV励磁（典型，可使用其他电压）	2500 mV励磁（典型，可使用其他电压）
模拟输出的热敏电阻	0至2500 mV（典型，取决于输入电压）	0至2500 mV（典型，取决于输入电压）	0至2500 mV（典型，取决于输入电压）	0至2500 mV（典型，取决于输入电压）	0至2500 mV（典型，取决于输入电压）	0至2500 mV（典型，取决于输入电压）	0至2500 mV（典型，取决于输入电压）
Calibration Uncertainty (-30 to 65 C), when target and detector ΔT are < 20 C	0.2摄氏度	0.2摄氏度	0.3 C	0.2摄氏度	0.2摄氏度	0.2摄氏度	0.2摄氏度
当目标和探测器ΔT<20 C时，校准不确定度（-40至80 C）	0.5 C	0.5 C	0.6 C	0.5 C	0.5 C	0.5 C	0.5 C
Measurement Repeatability	Less than 0.05 C	Less than 0.05 C	Less than 0.05 C	Less than 0.05 C	Less than 0.05 C	Less than 0.05 C	Less than 0.05 C
Response Time (time for detector signal to reach 95 % following a step change)	0.6 s	0.6 s	0.6 s	0.6 s	0.2秒	0.2秒	0.2秒
视野	22° half-angle	18° half-angle	14° half-angle	32° horizontal half-angle, 13° vertical half-angle	22° half-angle	18° half-angle	32° horizontal half-angle, 13° vertical half-angle
光谱范围	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window
Operating Environment	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)
Mass	190克	190克	190克	190克	190克	190克	190克

Analog Model Output (Difference between Target and Detector)

60 µV per C

40µV/C

20 µV per C

40µV/C

15µV/C

10 µV per C

Thermistor Input Voltage Requirement

2500 mV励磁（典型，可使用其他电压）

模拟输出的热敏电阻

0至2500 mV（典型，取决于输入电压）

Calibration Uncertainty (-30 to 65 C), when target and detector ΔT are < 20 C

0.2摄氏度

0.3 C

0.2摄氏度

当目标和探测器ΔT<20 C时，校准不确定度（-40至80 C）

0.5 C

0.6 C

0.5 C

Measurement Repeatability

Less than 0.05 C

Response Time (time for detector signal to reach 95 % following a step change)

0.6 s

0.2秒

视野

22° half-angle

18° half-angle

14° half-angle

32° horizontal half-angle, 13° vertical half-angle

22° half-angle

18° half-angle

32° horizontal half-angle, 13° vertical half-angle

光谱范围

8 to 14 µm atmospheric window

Operating Environment

-50 to 80 C, 0 to 100 % relative humidity (non-condensing)

Mass

190克

	SI-411-SS	SI-421-SS	SI-431-SS	SI-4H1-SS	SI-4HR-SS	SI-511-SS	SI-521-SS	SI-531-SS	SI-5H1-SS	SI-5HR-SS	sil - 411
Digital Input Voltage Requirement	5.5至24 V直流	5.5至24 V直流	5.5至24 V直流	5.5至24 V直流	5.5至24 V直流	5.5至24 V直流	5.5至24 V直流	5.5至24 V直流	5.5至24 V直流	5.5至24 V直流	5.5至24 V直流
Average Current Draw	1.5 mA (quiescent), 2.0 mA (active)	1.5 mA (quiescent), 2.0 mA (active)	1.5 mA (quiescent), 2.0 mA (active)	1.5 mA (quiescent), 2.0 mA (active)	1.5 mA (quiescent), 2.0 mA (active)	RS-232 quiescent 37 mA, active 37 mA; RS-485静止37，激活42 mA	RS-232 quiescent 37 mA, active 37 mA; RS-485静止37，激活42 mA	RS-232 quiescent 37 mA, active 37 mA; RS-485静止37，激活42 mA	RS-232 quiescent 37 mA, active 37 mA; RS-485静止37，激活42 mA	RS-232 quiescent 29 mA; RS-485 30 mA	1.5 mA (quiescent), 2.0 mA (active)
Calibration Uncertainty (0 to 50 C), when target and detector ΔT are < 20 C	0.2摄氏度	0.2摄氏度	0.3 C	0.2摄氏度	0.3 C	0.2摄氏度	0.2摄氏度	0.3 C	0.2摄氏度	0.5 C	0.5 C
Calibration Uncertainty (-30 to 65 C), when target and detector ΔT are < 20 C	0.2摄氏度	0.2摄氏度	0.3 C	0.2摄氏度	0.3 C	0.2摄氏度	0.2摄氏度	0.3 C	0.2摄氏度	0.5 C	-
当目标和探测器ΔT<20 C时，校准不确定度（-40至80 C）	0.5 C	0.5 C	0.6 C	0.5 C	0.5 C	0.5 C	0.5 C	0.6 C	0.5 C	1 C	-
Measurement Repeatability	Less than 0.05 C	Less than 0.05 C	Less than 0.05 C	Less than 0.05 C	Less than 0.05 C	Less than 0.05 C	Less than 0.05 C	Less than 0.05 C	Less than 0.05 C	Less than 0.05 C	Less than 0.05 C
Response Time (time for detector signal to reach 95 % following a step change)	0.6 s	0.6 s	0.6 s	0.6 s	0.6 s	-	-	-	-	-	0.6 s
视野	22° half-angle	18° half-angle	14° half-angle	32° horizontal half-angle, 13° vertical half-angle	16° horizontal half-angle, 5° vertical half-angle	22° half-angle	18° half-angle	14° half-angle	32° horizontal half-angle, 13° vertical half-angle	16° horizontal half-angle, 5° vertical half-angle	22° half-angle
光谱范围	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window	8 to 14 µm atmospheric window
Operating Environment	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)	-50 to 80 C, 0 to 100 % relative humidity (non-condensing)
Mass (with 5 m of cable)	190克	190克	190克	190克	219克	190克	190克	190克	190克	219克	190克

Digital Input Voltage Requirement
