大麻、小道消息、咖啡、菠菜和Strawberry settings now available for the Apogee MC-100 Chlorophyll Meter. Click the "New Coefficients" button below to learn how to add these species to your MC-100.
笔记：A recent software bug was discovered affecting MC-100 serial nubers 1525 - 1558. To fix this bug, you will need to follow the directions on this page:MC-100固件更新说明。
此错误导致连续发出哔哔声，校准冻结，以及找到校准文件的故障。
| MC-100. | |
|---|---|
| Default Display Unit | 每米μmol叶绿素2of leaf surface |
| Optional Display Units | CCI, SPAD |
| Measurement Area | 63.9 mm2(9 mm standard diameter), 19.6 mm2(5 mm diameter with reducer) |
| Resolution | ± 10 µmol m-2chlorophyll concentration using generic equation |
| 线性 | ± 1 % |
| Repeatability | ± 1 % |
| Sample Acquisition Time | 不到3秒 |
| 存储容量 | 8 MB for up to 160,000 data measurements; 94,000 data measurements with GPS data entries |
| 用户界面 | 50 mm乘15 mm图形显示屏，8个按钮，用于控制和数据操纵 |
| 数据输出 | Mini-B USB port provided for main data transfer |
| 测量变量 | 在931nm处的光传输比率为653 nm的光学传输 |
| 外部GPS选项 | RS-232 port (GPS location data is saved with each measurement) |
| Operating Temperature | 0到50 c |
| 温度漂移 | 温度补偿源和探测器电路在全范围内 |
| 电力需求 | 标准9 V DC碱性电池 |
| 方面 | 152毫米长，82毫米宽，25毫米高 |
| 大量的 | 210 G. |
向MC-100添加新物种
If you can't access the video via Youtube,click here。
Cannabis and Grapevine Settings Explained
If you can't access the video via Youtube,click here。
Chlorophyll Meter User Guide
If you can't access the video via Youtube,click here。
叶绿素仪表快速概述
If you can't access the video via Youtube,click here。
Chlorophyll Meter in Depth
If you can't access the video via Youtube,click here。
Lecture 7-Leaf Chlorophyll Concentration
叶绿素是在植物细胞，藻类细胞和蓝藻中发现的绿色颜料。叶绿素分子的主要功能是辐射吸收，为光合作用提供了必需的能量。
手持叶绿素米通常提供植物叶中叶绿素的相对指示。获得专利的Apogee模型MC-100叶绿素浓度计测量相对叶绿素含量，并以每米为单位的μmol单位输出实际叶绿素浓度的估计2of leaf surface (µmol m-2）;叶面积的质量，每平方米毫克（mg m-2），也已经使用过。
The MC-100 provides an alternative to destructive sampling techniques for determining chlorophyll concentration. Non-destructive measurements are less time consuming and labor intensive and allows for leaves to be measured and monitored over an entire growth cycle. The meter is designed to make rapid replicate measurements of the same leaf or multiple leaves and stores the data for later use.
申请包括：
• Chlorophyll concentration determination for plant nutrient status assessment, environmental stress impact, and fertilizer requirement
If you would like to share your application of this product, pleaseclick here
When Apogee released the MC-100, it came with 22 different crop specific coefficients plus a generic setting for all other crops. Since then, we have added some species and will continue to do so upon popular request. These new coefficients are linked to here and can be added following the instructions below.请注意，序列号小于1402的MC-100米仅被编程为能够一次保持最多27个裁剪特定系数。这可以是我们构建可用系数库的限制因素。如果您有一个具有此限制的单元，可以通过遵循链接的指令轻松升级软件这里>。
1。Extract the files contained in the zip file located in the link above.
2。Plug the micro USB cable into your MC-100's USB port.
3. Plug the other end of the USB cable into your computer.
4.打开MC-100，然后按“数据”按钮。MC-100现在应显示为计算机上的连接设备。
5. On your computer, access the MC-100. You should now see a list of files with a .tab extension.
6.使用其他.tab文件复制从zip文件中提取的新的.tab文件。
7. On the MC-100, press the "Eject" button.
1.在MC-100主菜单中，按“RUN”按钮。
2。Press the "Setup" button.
3.按一次“向上”箭头按钮一次访问“使用自定义测量”菜单。
4. Press the "Edit" button.
5.使用“向上”或“向下”箭头按钮将突出显示的选项从“否”更改为“是”。
6.按下“右”箭头按钮一次。
7.使用“向上”箭头和“向下”箭头按钮滚动系数文件并确认列出了新文件。
8.要使用自定义单元文件，只需按“接受”按钮。
